1,000,000 T/Y Ground Calcium Carbonate Grinding Production Line in Jiangxi
Core Equipment：CRRM2150 Raymond Mill（six）
Processed Materials：GCC（≤30mm）
Production Output：30t/h（Single unit）
Powder Fineness：325 mesh
In the early stages of the project, Cronus Machinery conducted extensive material-specific experiments, ultimately determining a solution involving six CRRM Raymond Mills operating in parallel. Since commissioning, the equipment has run with exceptional stability, meeting both output and fineness targets. Throughout the collaboration, communication was smooth and synergy was excellent.
—— Cronus Machine Customer
Project Overview
A calcium industry group in Jiangxi possesses over 11.3 million tons of mine reserves with a 30-year mining right. The mineral powder plant site covers an area exceeding 30,000 square meters, with a building floor area of over 10,000 square meters. To transform its abundant mine resources into an industrial chain, the group planned and constructed this modern heavy calcium carbonate production base with an annual capacity of one million tons. The core segment achieving this million-ton annual output adopted a design featuring 6 CRRM2150 Raymond Mills from Cronus Machinery operating in parallel. Through large-scale, intensive production, this has established the client's position as a core supplier within the heavy calcium carbonate industry chain in Jiangxi.
Project Details
Heavy Calcium Carbonate Mineral → Transfer Cooling Bin → Feeder → Raymond Mill
The process adopts a mode where 6 CRRM2150 Raymond Mills operate in parallel. Heavy calcium carbonate material is cooled in the transfer cooling bin and then fed into each Raymond mill via the feeder for grinding and pulverization. It is conveyed to the classifier by directional airflow generated by the fan. By precisely controlling the classifier parameters, the fineness of the heavy calcium carbonate powder is stably maintained at the 325 mesh standard.
Cyclone Collector → Pulse-Jet Bag Filter → Screw Conveyor → Bucket Elevator → Finished Product Silo
The cyclone collector serves as the primary collection device, separating and collecting the majority of heavy calcium carbonate fine powder. The pulse-jet bag filter acts as the secondary collection and environmental protection device, ensuring exhaust emissions meet standards and recovering heavy calcium carbonate ultra-fine powder. Finally, the collected finished heavy calcium carbonate powder is conveyed to the finished product silo via fully sealed screw conveyors and bucket elevators.
Main Equipment | Function Description |
Transfer Cooling Bin | Reduces the temperature of heavy calcium carbonate material |
Feeder | Continuously and uniformly distributes heavy calcium carbonate raw material to the 6 Raymond mills |
CRRM2150 Raymond Mill | Utilizes a parallel operation process with 6 Raymond mills to achieve large-scale production of 325 mesh heavy calcium carbonate powder |
Cyclone Collector | Separates and collects heavy calcium carbonate fine powder |
Pulse-Jet Bag Filter | Recovers heavy calcium carbonate ultra-fine powder and treats excess dust |
Screw Conveyor, Bucket Elevator | Centralizes and vertically conveys heavy calcium carbonate powder to the finished product silo |
Finished Product Silo | Stores finished heavy calcium carbonate powder, equipped with level indicators and discharge devices |
Project Advantages
Large-Scale Production: Features an ultra-strong configuration with 6 CRRM2150 Raymond Mills operating in parallel, with a single unit output of up to 30 t/h.
Stable and Efficient: Each CRRM2150 Raymond Mill can precisely control the finished product fineness, ensuring uniform particle size distribution of 325 mesh heavy calcium carbonate, meeting the demands of large-volume, high-standard supply.
Intelligent Control and Management: The centralized control system enables intelligent coordination and monitoring of the 6 main units and all auxiliary equipment throughout the line, significantly enhancing management efficiency.
