100,000 T/Y Limestone Ore Powder Production Line in Jiangsu
Core Equipment：CRRM1700 Raymond Mill
Processed Materials：Limestone（≤30mm）
Production Output：17t/h
Powder Fineness：200 mesh（D75）
The CRRM1700 Raymond Mill system—from conveying and grinding to collection and warehousing—is designed for simplicity and efficiency, making the entire production line easy to manage. The professional services provided by Cronus Machinery also contributed significantly to the smooth commissioning.
—— Cronus Machine Customer
Project Overview
Leveraging local resources, a building materials enterprise in Jiangsu decided to build a limestone powder production line. After comprehensive evaluation, the CRRM1700 Raymond Mill from Cronus Machinery was selected. This production line efficiently processes limestone into 200 mesh limestone powder with a high output of up to 17 t/h.
Project Details
Limestone Raw Material → Belt Conveyor → Raymond Mill
Limestone material meeting the required particle size is fed into the CRRM1700 Raymond Mill via the belt conveyor for grinding. The ground limestone powder is carried by the fan air flow into the classifier for precise classification. Limestone powder that does not meet the 200 mesh fineness requirement is separated by the classifier and falls back into the grinding chamber for re-grinding. Qualified limestone powder then enters the cyclone collector with the air flow for gas-solid separation.
Cyclone Collector → Screw Conveyor → Bucket Elevator → Finished Product Silo
The collected finished limestone powder is horizontally conveyed by a fully sealed screw conveyor to a bucket elevator, which then vertically lifts it to the finished product silo.
| Main Equipment | Function Description |
| Belt Conveyor | Continuously and stably feeds limestone raw material into the Raymond mill |
| CRRM1700 Raymond Mill | Grinds limestone with a particle size of ≤30mm into 200 mesh limestone powder |
| Cyclone Collector | Separates and collects the majority of qualified limestone powder |
| Screw Conveyor | Horizontally conveys finished limestone powder |
| Bucket Elevator | Vertically conveys finished limestone powder |
| Finished Product Silo | Stores finished limestone powder, equipped with a level gauge and discharge device |
Project Advantages
High and Stable Output: The CRRM1700 Raymond Mill achieves a single-unit output of up to 17 tons/hour, offering significant economies of scale and a high return on investment.
Easy Maintenance: The production line features a high degree of automation, simple operation and maintenance, effectively reducing long-term operating costs and labor requirements.
Compact Layout: The equipment layout is compact, meeting high-output demands while saving factory floor space and reducing capital investment costs.
